Fletch and his crew got together on a Very Hot day this last Monday. We took our normal precautions with frequent breaks under our awning, and drinking lots of water. Even with that, the sun felt like it was hovering 2 feet over our heads – LOL. But we pushed through and had a dirty, but great work session.
While we wait for the tender to get painted, we decided to start focused work on the Locomotive cab. We used grinders to get down to bare metal on half the cab roof, and some walls of the cab interior. Once the rust and old paint were removed, we applied a good quality, red metal primer. We hope this coat will provide a good level of protection on the metal skin until it gets some paint. Fletch did a lot of work inside the cab, while the rest of the crew worked on top of the cab. Now I have a better understanding of the phrase, “like a cat on a hot tin roof”.
We also got a look at the mahogany cab windows and doors that received a coat of primer from the restoration department’s last work session. They look great, and many thanks to Owen Hughes for his work. Finally, many thanks to Steve Pahl and Jay Slinde for all their help last Monday.
Once we identify our next work session, we will let you all know. Hope to see you there. – Jason Reiman
One of the next steps at SPEC Machine has been to finish the installation of the throttle rod and handle on the backhead of the boiler. Many of the new parts were shown in the December 25, 2020 update and now they have found their final home. The chromed end of the throttle rod has been mated to the long reach rod and is being fed through the boiler to the throttle proper. The half-lap and bolted connection is per the C&NW drawings and replaces the threaded coupling that was found when the throttle rod was disassembled.
Throttle rod installation in progress.
The packing gland was installed to properly position the rod so the throttle handle anchor could be properly located and studded to the boiler per the C&NW drawing.
Throttle packing gland and throttle handle anchor installed.
As another part of the 3-dimensional chess moves, the throttle handle support was mocked-up to check not only for correct placement of the handle but also proper clearance over the gauge-cocks and around the boiler stays.
Throttle handle support mock-up to check for clearances.
The original support was an “L” shape with the short leg pointed down. The new support has the short leg pointed up because the new boiler has a stay rod in the way of the old mounting. Here is a look at the completed assembly with the support studded to the backhead. The anchor does have a dog-leg in it per the C&NW drawings. It also does connect squarely at the stud end even though the camera lens distortion makes it look differently.
Throttle support.
Last but not least is a look down the top of the boiler from the throttle handle down to the throttle itself.
View of both the throttle and throttle rod.
In the next update: Installing the hydrostatic lubricator
